Product Details:
|
| Form: | Foil, Strip, Sheets ,plates, Coil,Tube | Original: | Taiyuan,China |
|---|---|---|---|
| Tolerance: | 0%-5% | Condtion: | Hot Rolled Cold Rolled |
| Finish: | Polished | Service: | Cutting |
| Process: | Cold Rolled | Durability: | Strong |
| Colour: | Silver | Type: | Plate, Plate |
| Technology: | Hot Rolled Or Cold Rolled | Stock: | Always In Stock |
| Standard Size: | 1500*6000mm 1219*2438MM | Finishing: | NO.1 / Black |
| Heat Treatment: | Optional | ||
| Highlight: | 12Cr13 Metal Plate,10 mm thick Metal Plate,4”x 8” Metal Plate |
||
|
Product Name
|
Stainless Steel Sheet/Plate | |||
| Material | 201,202,301,304,304L,304N,XM21,304LN,309S,310S,316,316Ti,316L, 316N,316LN,317,317L,321, 904L, 2205 |
|||
| Surface |
BA/2B/NO.1/NO.3/NO.4/8K/HL/2D/1D
|
|||
|
Size
|
1220*2440, 1500*6000
|
|||
|
Thickness
|
0.1-120mm
|
|||
|
Length
|
1000 - 6000mm or as your request, 1000 - 6000mm or as you request
|
|||
|
End/Edge
|
Plain Mill
|
|||
|
Standard
|
ASTM DIN GB JIS EN AISI
|
|||
|
Grade
|
201/304/304L/321/316/316L/310S/904L/309S/316Ti/317L/2205/2507, etc.
|
|||
|
Technique
|
Cold Rolled,Hot Rolled or Welded
|
|||
|
Certification
|
ISO9001, SGS, BV, ISO, CE
|
|||
|
Used
|
Building Industry Machinery, etc.
|
|||
|
MOQ
|
1 Ton
|
|||
|
Payment terms
|
L/C at sight or T/T (30% as deposit)
|
|||
|
Packing
|
Export standard package or as customers' request
|
|||
|
Delivery time
|
Usually 7-15 dyas, or upon negotiation
|
|||
|
Price terms
|
FOB,CRF,CIF,EXW all acceptable
|
|||
|
Samples
|
Free samples are provided but the fright is borne by the buyer
|
|||
|
Surface Finished
|
Characteristics
|
application
|
|
NO.1
|
Finished by hot-rolling, smoother and pickling, characterized by white pickled surface.
|
Chemical industry equipment, Industrial tanks.
|
|
2B
|
Finished by anneal treatment, pickling after cold rolling, followed by skin pass line to more brighter and smoother surface.
|
General application medical instruments, Tableware.
|
|
BA
|
Bright anneal treatment after cold rolling.
|
Kichen utenstil, Kitchen ware,Architectural purpose.
|
|
NO.4(Satin)
|
Finished by incontinuous linear brushing
|
Architecture,industries,Escalators, Kitchen ware, Vehicles.
|
|
Hairline
|
Finished by continuous linear brushing
|
Architecture,industries,Escalators, Kitchen ware, Vehicles.
|
|
8K(mirror)
|
A mirror-like reflective surface by polishing with finer abrasives over 800 mesh.
|
Refletor, Mirror, Interior- Exterior decoration for building.
|
AISI 410 stainless steel is one of the most commonly used martensitic stainless steels. It contains about 12% Cr and therefore provides moderate corrosion resistance. Unlike austenite such as AISI 304 and AISI 316, martensite such as grade 410 is magnetic and can be hardened by heat treatment like carbon steel and low alloy steel. SS410 has good tensile strength, creep and fatigue strength and other mechanical properties, mainly used in steam turbines, jet engines and gas turbines.
Type 420 is basically a high-carbon version of SS410 which provides higher strength. Ferritic stainless steel 430 contains a higher chromium content, so it has higher corrosion resistance.
The following tables and lists give the stainless steel 410 datasheet and specification including chemical composition, physical properties and mechanical properties, heat treatment, welding, etc.
SS 410 material chemical composition is listed in the following table based on cast analysis.
Datasheet 1, The table below shows AISI 410 stainless steel composition.
| Type 410 Chemical Composition, % | ||||||||
| ASTM / SAE | AISI (UNS) | C | Si, ≤ | Mn, ≤ | P, ≤ | S, ≤ | Cr | Ni, ≤ |
| ASTM A276/A276M | 410 (UNS S41000) | 0.08-0.15 | 1.00 | 1.00 | 0.040 | 0.030 | 11.5-13.5 | – |
| ASTM A580/A580M | 0.15, ≤ | 1.00 | 1.00 | 0.04 | 0.03 | 11.5-13.5 | – | |
| ASTM A959 | ||||||||
| ASTM A479/A479M | ||||||||
| ASTM A314 | ||||||||
| ASTM A240/A240M | 0.08-0.15 | 1.00 | 1.00 | 0.04 | 0.03 | 11.5-13.5 | 0.75 | |
| ASTM A473 | 0.15, ≤ | |||||||
| SAE J405 | 0.15, ≤ | |||||||
Notes:
The datasheets below list grade 410 stainless steel properties including physical properties and mechanical properties.
SS 410 stainless steel physical properties are listed in the table below such as density, melting point, specific heat, electrical resistivity, elastic modulus (modulus of elasticity), thermal conductivity, and coefficient of thermal expansion (CTE).
Q1. How do you control quality ?
A1: Mill Test Certification is supplied with shipment, Third Party Inspection is available. and we also get ISO,SGS,
Q2: What is the terms of packing?
A2: generally, we pack our goods in bundles or coils with rods or belts, we could also pack the goods as the customers requirement.
Q3:What is your delivery time?
A3: For stocks, we could transport the goods to loading port within 7 days after we received your deposit
For production period, it usually takes about 15 days-30 days after receiving the deposit.
Q4. What are the advantages of your company ?
A4: We have many professionals, technical personnel, more competitive prices and best after-dales service than other stainless steel companies.
Q5. How many coutries you already exported ?
A5: Exported to more than 100 countries mainly from America, Russia, UK, Kuwait, Egypt, Turkey, Jordan,India, etc.
Q6. Can you provide sample ?
A6: We can provide the samll samples in stock for free, as long as you contact us.
Customized samples will take about 5-7days.
