Product Details:
|
| Processing Service: | Bending, Welding, Cutting | Shape: | Flat.sheet |
|---|---|---|---|
| Tensile Strength: | 95,000 Psi | Dimensions: | As Per Drawings |
| Characteristics: | Good Sound-absorbing Effect | Package: | Standard Sea Worthy Package |
| Heat Treatment: | Q+T（quenched And Tempered） | Surface: | Bright,Polished |
| Port: | Shanghai | Oem Service: | Yes |
| Length: | 96 Inches | Thinckness: | 1mm-30m |
| Packge: | Wooden Pallet | ||
| Highlight: | Pressure Vessel Steel Plate,18*2200*12000MM Boiler Steel Plate |
||
|
Product Name
|
A387 Boiler steel plate
|
|
Thickness
|
6-150mm
|
|
Width
|
1000-3000mm (1000-2200mm usually used)
|
|
Length
|
1000-20000mm or as your request
|
|
Surface
|
Clean, finishing,blasting and painting according to customer requirement
|
|
Delivery
States
|
Hot-rolled, Controlled rolling, Normalizing, Annealing, Tempering;
Quenching,N+T,Q+T ,and other delivery states are available as required
|
|
Certificate
|
API,ISO,SGS,BV,CE etc
|
|
Quality certificate
|
MTC will be provided with goods,SGS or any third part inspection is acceptable
|
|
Pricing Term
|
FOB,CFR,CIF
|
|
Package
|
Standard export seaworthy package,suit for all kinds of transport, customized
|
|
Application
|
Widely used in a variety of architectural and engineering structures,such as 1.) metal constructions such as
buildings,bridges,ships; 2.) transmission tower, reaction tower; 3.) lifting transportation machinery; 4.) industrial furnace;boilers 5.) container frame, warehouse goods shelves, etc |
Features of A387 gr 11 pressure vessel steel plate:
The Molybdenum component in A387 gr 11 pressure vessel steel plate increases the plate tensile strength at high temperatures, and it also provides high resistance against oxidation and corrosion by increasing the lattice strain of the steel structure. That effectively stops the corrosive agents from dissolving the iron out of the steel structure.A387 gr 11 pressure vessel steel plate is good option for heat-resistant pressure vessels and sour gas environments.
Application of A387 gr 11 pressure vessel steel plate:
A387 gr 11 pressure vessel steel plate is popular used by power plant and dignity health medical foundation oil and gas industries in the production facilities because of the alloy's key properties.
Equivalent grades of A387 gr 11 pressure vessel steel plate:
| USA | USA | EUROPEAN | GERMANY |
UK (BRITISH STANDARD) |
FRANCE | RUSSIA | |
| STANDARDS | ASTM | ASME | EN 10028 | DIN | BS | AFNOR 36206 | GOST |
| GRADE | A387 11 | SA387 11 | 13CrMoSi5-5 | --- | 621B |
|
SA387/ASTM A387
|
Grade 5
|
Grade 9
|
Grade 11
|
Grade 12
|
Grade 22
|
|
C
|
0.15 max
|
0.15 max
|
0.04 - 0.17
|
0.04 - 0.17
|
0.04 - 0.15
|
|
Mn
|
0.25 - 0.66
|
0.25 - 0.66
|
0.35 - 0.73
|
0.35 - 0.73
|
0.25 - 0.66
|
|
P
|
0.035
|
0.030
|
0.035
|
0.035
|
0.035
|
|
S
|
0.030
|
0.030
|
0.035
|
0.035
|
0.035
|
|
Si
|
0.55 max
|
1.05 max
|
0.44 - 0.86
|
0.13 - 0.45
|
0.5 max
|
|
Cr
|
3.9 - 6.1
|
7.9 - 10.1
|
0.94 - 1.56
|
0.74 - 1.21
|
1.88 - 2.62
|
|
Mo
|
0.40 - 0.7
|
0.85 1.15
|
0.40 - 0.7
|
0.4 - 0.65
|
0.85 - 1.15
|
|
Grade
|
A 387 Grade 5 &
Grade 9
|
A 387 Grade 11
|
A 387 Grade 12
|
A 387 Grade 22
|
||||
|
Class 1
|
Class 2
|
Class 1
|
Class 2
|
Class 1
|
Class 2
|
Class 1
|
Class 2
|
|
|
Tensile Strength (ksi)
|
60-85
|
75-100
|
60-85
|
70-90
|
50-80
|
65-85
|
60-85
|
75-100
|
|
Tensile Strength (MPa)
|
415-585
|
515-690
|
415-585
|
485-620
|
380-550
|
450-585
|
415-585
|
515-690
|
|
Yield Strength (ksi)
|
30
|
45
|
35
|
45
|
33
|
40
|
30
|
45
|
|
Yield Strength (MPa)
|
205
|
310
|
240
|
310
|
230
|
275
|
205
|
310
|
|
Elongation in 200mm (%)
|
|
|
19
|
18
|
18
|
19
|
|
|
|
Elongation in 50mm (%)
|
18
|
18
|
22
|
22
|
22
|
22
|
18
|
18
|
