Product Details:
|
| Application: | Construction,Kitchenware,Decoration,chemical,Industry | Width: | 1000-2000mm |
|---|---|---|---|
| Type: | Plate,stainless Steel Sheet | Standard: | ASTM,JIS,AISI,EN |
| Length: | 1000-6000mm Or Customer's Requirement | Grade: | 300 Series |
| Thickness: | 0.2-60mm | Edge: | Slit Edge,Mill Edge |
| Technique: | Cold Rolled Finish | Price Term: | CIF CFR FOB EX-WORK |
| Item: | ISO9001 Standard,Stainless Steel Sheet | ||
| Highlight: | Medical Grade Stainless Steel Sheet,316LVM Stainless Steel Sheet,1.5mm Stainless Steel Sheet |
||
Implant steel with improved corrosion resistance compared to AISI 316L.
Osteosyntheses; bone screws, bone plates, marrow-nails. Also suitable for watch industry.
| C | ≤ 0,030 | Cr | 17,0 - 19,0 |
| Si | ≤ 1,00 | Mo | 2,5 - 3,2 |
| Mn | ≤ 2,0 | Ni | 13,0 - 15,5 |
| P | ≤ 0,025 | N | ≤ 0,10 |
| S | ≤ 0,010 | Fe | rest` |
| annealed | specification values (bars) |
| tensile strength Rm | 490 - 690 MPa |
| elongation A | ≥ 40% |
| cold worked | specification values (bars) |
| tensile strength Rm | 860 - 1100 MPa (higher values upon demand) |
| elongation A | ≥ 12% |
| dimensions | kg/m2 | tolerances |
| 3,2 | 0,226 | +0 / - 0.1 mm |
| 4,5 | 1.013 | +0 / - 0.1 mm |
| dimensions | kg/m | tolerances |
| 6,0 | 0,22 | h8 |
| 8,0 | 0,40 | h8 |
| 12,7 | 1.01 | h8 |
Further bars and profiles in different executions available upon request.
Various sizes and tolerances available upon request.
We can provide various services directly in our service center. You save time, cost (internal or external) and don't need to find solutions for scrap management or handling of heavy plates and long bars.
| Services suitable for sheets, plates, coils | Services suitable for round bars |
| laser and waterjet cutting | sawing of bars |
| shearing of sheets and plates | bar marking |
| coil slitting | turning machine |
